Cisco Aironet AIR-AP1852E-E-K9 wireless

Mô tả

Cisco Aironet AIR-AP1852E-E-K9 wireless 1850 Access Point Dual-band

Integrated antennas	– 2.4 GHz, gain 3 dBi, external omni, horizontal beamwidth 360° – 5 GHz, gain 5 dBi, external omni, horizontal beamwidth 360°
Interfaces	– 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) – 1 x 10/100/1000BASE-T autosensing (RJ-45), AUX (used for Link Aggregation) – Management console port (RJ-45) – USB 2.0 (enabled via future software)
Indicators	– Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
Dimensions (W x L x H)	– Access point (without mounting bracket): 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm)
Weight	– 3.12 lb (1.41 kg)
Environmental	– Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C) – Nonoperating (storage) altitude test: 25˚C, 15,000 ft. – Operating temperature: -4° to 122°F (-20° to 50°C) – Operating humidity: 10% to 90% (noncondensing) – Operating altitude test: 40˚C, 9843 ft.
System	– 1 GB DRAM – 256 MB flash
Powering options	– 802.3at – Enhanced PoE – Cisco power injector, AIR-PWRINJ4= – Cisco local power supply, AIR-PWR-C= – Cisco power injector, AIR-PWRINJ5= (Note: this injector supports 802.3af only) – 802.3af Note: If 802.3af PoE is the source of power, (1) the 1852e 2.4-GHz radio will shift to 2×3 from 3×4, (2) The USB port and AUX Ethernet port are disabled on both the 1852i and 1852e.
Power draw	– 20.9W Note: When deployed using a Power over Ethernet (PoE) specification, the power drawn from the power sourcing equipment will be higher by some amount, depending on the length of the interconnecting cable.
Physical security	– Torx security screw, included with the access point
Accessories	– Mounting bracket: AIR-AP-BRACKET-8= (available as spare) – Physical security kit: AIR-SEC-50= (sold separately), with 50 pcs. security screws used to secure the access point onto wall-mounting bracket, 50 pcs. RJ-45 caps and 2 pcs. unlock keys used to block physical access to Ethernet ports
Compliance	– Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1 – Radio approvals: FCC Part 15.247, 15.407, RSS-247 (Canada), EN 300.328, EN 301.893 (Europe), ARIB-STD 66 (Japan), ARIB-STD T71 (Japan), EMI and susceptibility (Class B), FCC Part 15.107 and 15.109, ICES-003 (Canada), VCCI (Japan), EN 301.489-1 and -17 (Europe), EN 50385 – IEEE standards: IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d, IEEE 802.11ac – Security: 802.11i, WPA2, WPA, 802.1X, AES – Extensible Authentication Protocol (EAP) types: EAP-Transport Layer Security (TLS), EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2), Protected EAP (PEAP) v0 or EAP-MSCHAPv2, EAP-Flexible Authentication via Secure Tunneling (FAST), PEAP v1 or EAP-Generic Token Card (GTC), EAP-Subscriber Identity Module (SIM) – Multimedia: Wi-Fi Multimedia (WMM) – Other: FCC Bulletin OET-65C, RSS-102
Software	Cisco Unified Wireless Network Software Release with AireOS wireless controllers: – 8.1 MR1 or later for the Cisco Aironet 1850 Series Access Points
Deployment modes	Centralized, standalone, sniffer^, Cisco FlexConnect^™, monitor^, OfficeExtend^, mesh^
Supported wireless LAN controllers	– Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Cisco Catalyst^® 6500 Series Switches, Cisco 5500 Series Wireless Controllers, Cisco 5520 Series Wireless Controllers, Cisco Flex^® 7500 Series Wireless Controllers, Cisco 8500 Series Wireless Controllers, Cisco 8540 Series Wireless Controllers, Cisco 5760 Wireless LAN Controller,^ Cisco Catalyst 3650 and 3850 Series Switches with integrated controller^ – Cisco Mobility Express
802.11n version 2.0 (and related) capabilities	– 4×4 MIMO with four spatial streams – Maximal ratio combining (MRC) – 20- and 40-MHz channels – PHY data rates up to 600 Mbps (40 MHz with 5 GHz) – Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) – 802.11 dynamic frequency selection (DFS) – Cyclic shift diversity (CSD) support
802.11ac Wave 1 and 2 capabilities	– 4×4 MIMO with four spatial streams, single-user MIMO – 4×4 MIMO with three spatial streams, multiuser MIMO – MRC – 802.11ac beamforming (transmit beamforming) – 20-, 40-, and 80-MHz channels – PHY data rates up to 1.7 Gbps (80 MHz in 5 GHz) – Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) – 802.11 DFS – CSD support – Rogue device detection
