Aruba Mobility Controller 7205 (RW) (JW735A)

Concurrent IPsec sessions	8192
Firewall throughput	12 Gbps
Encrypted throughput (3DES, AES-CBC)	5 Gbps
Encrypted throughput (AES-CCM)	5 Gbps
Form factor/footprint	1 rack unit
Auto-negotiating 10/100/1000BASE-T	4 combo
10 Gigabit Ethernet ports (GBIC or SFP)	2
USB 2.0	Yes
Management/status LEDs	Yes (2)
LINK/ACT and status LEDs	Yes
LCD panel and navigation buttons	No
Console port	Yes (micro USB/RJ-45)
Out-of-band management port	Yes
PoE Role/Mode	Power Source Equipment (PSE)
PoE In or Out	Out
Number of PoE+ capable Ports	24
Max concurrent of PoE Ports	24
Max concurrent PoE+ Ports	5
PoE Power Budget	400W
Dimension (H × W × D)	(H) 4.4 cm x (W) 44.2 cm x (D) 33.4 cm (1.75” x 17.38” x 13.13”)
Weight	4.95 kg (10.19 lbs.)
MTBF (hours, @ 25C)	129,597 (@40C
Operating temperature	0° C to 40° C
Storage temperature	-40° C to 70° C
Humidity/storage humidity	10% to 95%
NC Operating altitude	10,000 feet
Acoustic noise	39.8 – 58.6 dBA
Maximum power consumption	190W (with PoE)
Telco	Common Language Equipment Identifier (CLEI) Code
Regulatory SKU information	ARCN7205
Minimum ArubaOS Release	6.4.3.0

Bảng hiệu năng và công suất hoạt động Aruba 7200 controllers

Model	7205	7210	7220	7240XM	7080
Maximum campus AP licenses	256	512	1024	2048	2048
Maximum remote AP licenses	256	512	1024	2048	2048
Maximum concurrent users/devices	8,192	16,384	24,576	32,768	32,768
Maximum VLANs	4,096	4,096	4,096	4,096	4,096
Active firewall sessions	1,000,000	2,015,291	2,015,291	2,015,291	2,015,291
Concurrent GRE tunnels	4096	8192	8192	8192	8,192
Concurrent IPsec sessions	8192	16384	24,576	32,768	32,768
Firewall throughput	12 Gbps	20 Gbps	40 Gbps	40 Gbps	100 Gbps
Encrypted throughput (3DES, AES-CBC)	5 Gbps	7 Gbps	27 Gbps	29 Gbps	57 Gbps
Encrypted throughput (AES-CCM)	5 Gbps	6 Gbps	22 Gbps	29 Gbps	79 Gbps
