JW3208 FC/SC/ST fiber opti
Liên hệ để báo giá
In StockJW3208 FC/SC/ST fiber optic power meter
- Power Supply: 3 pcs1.5V AA batteries
- Measurement Range(dBm): -70~+3/-50~+26
- Model Number: JW3208
- Measurement Range(dBm): -70~+3/-50~+26
- Product description: JW3208 FC/SC/ST fiber optic power meter
Mô tả
Type |
JW3208A |
JW3208C |
Wavelength(nm) |
800~1700nm |
|
Detector |
InGaAs |
|
Measurement Range (dBm) |
-70~+3 |
-50~+26 |
Uncertainty |
±5% |
|
Calibrated Wavelength(nm) |
850,980,1300,1310,1490,1550 |
|
Resolution(dB) |
0.01 |
|
Optical Connector |
FC(interchangeable SC,ST) / as well as 2.5mm universal |
|
Power Supply |
Alkaline Battery(3 AA 1.5V batteries) |
|
Battery Operating Time |
240 h with 1.5V Battery(3) |
|
Operating Temperature(°C) |
-10 ~ +60 |
|
Storage Temperature(°C) |
-25 ~ +70 |
|
Relative Humidity |
0 to 95% (non-condensing) |
|
Dimension(mm) |
175x82x33 |
|
Weight(g) |
310 |
Standard Packages
MODEL |
INCLUDES |
All JW3208 Models |
JW3208 Optical Power Meter, Protective Rubber Boot, 3pcs 1.5V batteries, User Manual, Cotton swabs and Soft carrying case. |
